Displacement
Max Power
Top Speed
Ground Clearance
The EJ350ATV is a mid-size all-terrain vehicle designed for both utility work and recreational riding. Powered by a 288ml single-cylinder engine with selectable 4×2 / 4×4 drive, it delivers balanced performance, solid off-road capability, and reliable handling across varied terrains.
For general inquiries, introductions, or early-stage discussions, please use the short form below.
No technical details required.
Delivers stable and efficient power output suitable for off-road riding and daily utility tasks.
Provides responsive acceleration and dependable performance across trails and rough terrain.
Flexible drive modes improve traction and adaptability in mud, dirt, and uneven surfaces.
Balanced speed range suitable for both recreational riding and outdoor work applications.
Shorter overall length enhances maneuverability and control, especially useful on narrow forest trails and off-road paths.
For general inquiries, introductions, or early-stage discussions, please use the short form below.
No technical details required.
Front and rear independent suspension systems provide improved ride comfort and better terrain absorption, which is easily visible in product photos.
For general inquiries, introductions, or early-stage discussions, please use the short form below.
No technical details required.
Strong braking system ensures stable stopping power and reliable safety performance during off-road riding.
For general inquiries, introductions, or early-stage discussions, please use the short form below.
No technical details required.
Optional mud configuration enhances off-road capability with improved adaptability for challenging terrain conditions, making it suitable for specialized outdoor use.
For general inquiries, introductions, or early-stage discussions, please use the short form below.
No technical details required.
| Engine Type | EJ350ATV |
| Engine Type | Single cylinder, four stroke, SOHC, water cooling，uniaxal balance |
| Bore x Stroke | 75×65mm |
| Displacement | 288ml |
| Max. Torque | 28N.m / 5000r/min |
| Max. Power | 17kw / 6800r/min |
| Spark Plug Type | D8RTC / DR8EA NGK |
| Starting Type | Electric start |
| Gear Shift / Order | Manually / L—H—N—R |
| Lubricating Oil & Usage | SL 10W/40（GB 11121-2006）/1800ml |
| Transmission | (CVT) + Gear shift |
| Drive System | Selectable 4×2 / 4×4 / 4×4-lock |
| Top Speed | 75 km/h |
| Battery Capacity | 12V12Ah |
| Overall Size (L×W×H) | 1940×1200×1220MM |
| Wheelbase | 1350mm |
| Tread | 970mm |
| Ground Clearance | 320mm |
| Min. Turning Radius | 3700 mm |
| Dry Weight | 320 kg |
| Front Suspension | Double A-arm independent suspension |
| Rear Suspension | Double A-arm independent suspension |
| Front / Rear Brakes | Dual hydraulic disc |
| Parking Brake | Hand-Actuated |
| Front Tires | ATV 25×8-12 |
| Rear Tires | ATV 25×10-12 |
| Wheels | Aluminum alloy |
| Carburetor (Std.) |
| Winch & Side Bars |
| EFI Version |
| Mud Version |
| EPS |
